Wood & sawmill technology
Frame saw technology
High-speed oscillating frame saws for high feed rates and good surfaces – proven technology, precisely integrated.
Partner EWD
01Performance
What it does.
Many cuts, one pass
Several blades in the frame divide the cant at the same time.
Good surfaces
The oscillating frame produces clean cut faces at high feed rates.
Robust and proven
Simple, durable mechanics with manageable maintenance.
Precisely integrated
Infeed, feed rollers and outfeed determine how well the frame saw performs.
02Context
Where in the process.
Wood & sawmill
01 / 07
- 01Log yardLog handling
- 02BreakdownLog band saw, reducer or frame saw – depending on diameter, species and capacity.Log band saw technologyReducer band saw technology● This page
- 03EdgingEdging technology
- 04ProfilingCircular saw & profiling technology
- 05Sorting & stackingSawn timber handling
- 06GlulamGlulam handling
- 07ResiduesShredding technology
03Markets
Typical materials.
These are the markets where we typically use this technology. Each tile leads to the matching solution.
Design sheet
VT-12-S
Input
Log or cant
Output
Many boards per pass
Design parameters
- P01Passage width
- P02Number of blades
- P03Feed rate
- P04Kerf
- P05Diameter range
Guide only – project-specific design required. We define the actual values together with you.
Schematic, not to scale
04Engineering
Machine types & parameters.
Typical machine types
- 01
Oscillating frame saws
High-speed frame saws with an oscillating frame for high feed rates.
- 02
Primary & secondary frame saws
A classic pairing: the first frame saw cuts the cant, the second divides it.
- 03
Infeed & turning systems
Centre the log and turn the cant by 90° between the frame saws.
- 04
Outfeed & separation
Separate boards and side boards behind the frame saw and move them on.
05References
From our projects.
Partner technology
Technology from our partners.
EWD
Altötting & Reutlingen, Germany
Since 1862
Sawmill technology from a single source – rooted in Esterer (since 1862) and Wurster + Dietz (since 1867).
The machine technology typically comes from EWD. Vecotrade plans the plant, integrates the machines into your material flow, installs, commissions and remains your point of contact.
06Contact
Your project. One contact.
Describe your material, goal and constraints – we will get back to you with a first assessment. Your enquiry is already pre-filled with this technology.
FAQ
Frequently asked questions.
01Is frame saw technology still up to date?
For many mills, yes. Modern oscillating frame saws achieve high feed rates and good surfaces and are robust in operation. Whether they are right for your assortment, we compare against band saw and reducer solutions.
02How does a frame saw differ from a band saw?
The frame saw cuts with many blades at once in a single pass; the band saw uses one blade – but with a cutting decision for each log. Frame saws excel with a uniform assortment, band saws with a changing one.
03Can existing frame saws be kept?
Existing frame saws can often be integrated into a modernised line, for example with a new infeed or outfeed. We check condition and installation on site.
